Wire Mesh type shot blasting machine is through high-speed projectile impact on the surface of the workpiece, can effectively remove the surface coating and peeling, improve the surface roughness and adhesion of the workpiece ‌, the net belt is one of the important parts of this equipment, it always runs through the whole radial shot blasting belt arranged by the upper and lower shot blasting machine to accept high-speed cutting of the projectile flow for a long time, so the net transmission belt itself has become vulnerable parts. Therefore, the high wear-resistant transmission belt  made of rolled Mn13 is selected to ensure long service life and improve the production efficiency of the equipment.

Wire Mesh type shot blasting machine It mainly has the characteristics of small continuity, high cleaning efficiency, small deformation, no pits, compact structure, environmental protection performance, wide application range, etc., can be used alone, can also be used in multiple combinations.

Wire Mesh belt type shot blasting machine is mainly used for surface treatment and shot blasting strengthening of thin wall casting, thin wall iron, aluminum alloy castings, ceramic and other small work-piece with features of continuous performance, high cleaning efficiency, small deformation, no pit etc. It can be used alone or can be used with other shot blasting machine.
This machine provides high volume, cost effective performance for all metal processing requirements. They will handlelarge die castings, automotive wheels, ferrous and non-ferrous castings, weldments, fabrications and more.

Mesh belt shot blasting machine can be used very flexibly and easily integrated into a continuous production line.

Xinke offers large shot blasting machines which allow high volume and complex parts to be shot blasted with no manual blasting. The parts are passed through the shot blaster on a wire mesh conveyor belt. The impurities such as oxide, welding slag and oil on the surface will be removed, and the surface will get a certain roughness, so as to achieve the surface treatment effect.

A highly wear-resistant wire mesh belt, with tension adjustment, provides the part transport. High volume of batches and fast consistent shot blasting can be achieved very easily.

Place workpieces on the conveyor belt, the shot blasting chamber is equipped with powerful turbines around the housing, while the turbines are rotating at high speed, which allows them to treat very complex components, especially workpiece with “pockets” or difficult to reach areas.

Preservation lines combine the heating (drying), blasting, coating and drying of workpieces such as sheet steel, profiles, pipes or steel structures in one automatic line.

Preservation lines are ideal when there is a lengthy manufacturing or storage time between blasting and final coating. In order to prevent rust returning, a weld primer is applied to provide corrosion resistance for weeks.

Sheet widths of up to 5000mm can be processed, with passage speeds varying from 1.0m/min to 8.0m/min.

In addition, the high-end equipment may use touch screen, computer monitoring and other systems. Electronic control system is a very important part of the steel plate pretreatment line, a better electronic control system can maximize the productivity of the equipment, extend the service life of the equipment, save electricity, paint, heat and labor consumption.

Due to the complex working process of the steel plate pretreatment line, it is basically impossible to manually operate, so the automatic control is a necessary condition for the steel plate pretreatment line. Generally use PLC programmable controller, the most basic is to realize the automatic opening of the equipment to the ready work state, the equipment will automatically collect data after loading, and then accurately judge the shot blasting switch time, control the spray paint width, etc. Audible or optical alarm can be used when the equipment is faulty until the equipment is automatically shut down.

In addition, the high-end equipment may use touch screen, computer monitoring and other systems. Electronic control system is a very important part of the steel plate pretreatment line, a better electronic control system can maximize the productivity of the equipment, extend the service life of the equipment, save electricity, paint, heat and labor consumption.

Xinke preservation line is a highly complex, individually configured surface treatment system that fully automatically pre-heats, derusts, and descales and then applies a temporary corrosion protection – the welding primer – to steel.

Its purpose is to improve the corrosion resistance and fatigue resistance of the steel plate, extend the service life, and optimize the surface state of the steel plate to facilitate subsequent processing.

Preservation lines can take on enormous dimensions, a complete preservation line that can be easily integrated seamlessly into a customized production line, this ensures a flexible production process and a high material output.

Xinke preservation line is a highly complex, individually configured surface treatment system that fully automatically pre-heats, derusts, and descales and then applies a temporary corrosion protection – the welding primer – to steel.

Its purpose is to improve the corrosion resistance and fatigue resistance of the steel plate, extend the service life, and optimize the surface state of the steel plate to facilitate subsequent processing.

Preservation lines can take on enormous dimensions, a complete preservation line that can be easily integrated seamlessly into a customized production line, this ensures a flexible production process and a high material output.

Roller conveyor lines are an essential part of the overall preservation system. The components (steel plate, steel pipe or steel section) continuously pass through the pre-treatment chamber, the blasting chamber and the cleaning chamber, on a special roller conveyor. The high performance turbines mounted on the blasting chamber ensure full coverage under controlled process conditions, and result in the desired cleaning effect.

We are a professional steel plate surface treatment line manufacturer. Steel plates can be processed in widths ranging from 1m to 6m. It can also handle general structural steel, such as angle steel, channel steel, I-beam, etc.

Our through - type (pass - type) shot blasting machine is a top 10 universal industrial workhorse. Ideal for metal surface treatment, it features a continuous conveying system for seamless large - scale production. Multiple shot blasters in a 3D array ensure 360° non - dead - angle treatment of plates, castings, and more.

This machine efficiently removes rust, paint, and contaminants, while enhancing metal's mechanical properties by inducing compressive stresses.excels in removing rust, scale, old paint, and contaminants from plates, structural steel, castings, and forgings. Beyond cleaning, it simultaneously improves the metal's mechanical properties by inducing compressive stresses, which significantly enhances fatigue life and durability. Engineered for productivity, its continuous operation ensures maximum throughput with minimal manual handling.

Equipped with a high - efficiency dust collection system (99.97% removal, 3mg/m³ emission), it meets environmental standards. The intelligent PLC control and modular design allow for easy operation and quick component replacement, achieving one - machine multi - purpose.

Pass Through Type Shot Blasting Machine is an industrial system designed for the high-efficiency, continuous cleaning, descaling, or surface preparation of workpieces. Unlike batch-type machines, it processes components on a conveyor system, typically a rubber belt or roller conveyor, allowing them to pass through an enclosed blast chamber in a steady flow. This makes it ideal for high-volume production environments.

The primary application of through-type shot blasting machines is in heavy industries requiring continuous processing. They are extensively used for:  Cleaning structural steel sections, plates, and profiles before painting in construction and bridge projects.  Processing large volumes of automotive components like axles, springs, and forged parts.  Descaling and cleaning metal sheets, bars, and pipes in steel mills and pipe manufacturing plants.  Cleaning castings and forgings in foundries and forging operations to remove sand and scale.  Pre-treating railway components and wheelsets.  In summary, the through-type shot blasting machine is a cornerstone of modern industrial surface treatment, offering automated, efficient, and consistent preparation of metal surfaces for subsequent finishing, protection, or assembly processes.

A Pass-through Shot Blasting Machine is a continuous operation system designed for the high-efficiency cleaning and surface preparation of a wide range of components. As the name suggests, workpieces "pass through" a sealed chamber on a conveyor system, making it ideal for high-volume production lines and treating large, standardized items.

The core principle involves a centrifugal blast wheel. This wheel propels steel shot at high velocity onto the surfaces of the components passing through the enclosure. This abrasive impact effectively removes rust, mill scale, old paint, and contaminants. The machine incorporates a sophisticated recycling system that collects the used shot, separates the debris, and returns the clean abrasives to the wheel for reuse, ensuring a continuous and economical operation.

The primary advantage of this design is its unmatched efficiency and automation. Models like the Roller Conveyor Shot Blasting Machine allow for the effortless processing of long, heavy, or flat items such as H Beams, steel plates, and even alloy wheels. This eliminates slow, labor-intensive manual methods. The process is not only fast but also delivers a uniform surface profile, crucial for subsequent coating adhesion. Furthermore, the shot peening action imparts compressive stresses, enhancing the fatigue life of the treated parts.

In summary, from dedicated H Beam Shot Blasting Machines to versatile roller shot blasting machines, the pass-through design is a cornerstone of modern industrial manufacturing, offering a blend of speed, consistency, and automation for superior surface treatment.

Pass Type Shot Blasting Machine is an industrial workhorse designed for the continuous, high-volume cleaning and surface treatment of metal workpieces. Imagine a robust chamber where components pass through on a conveyor system while being bombarded by a high-velocity stream of abrasive media (shot). This process, known as shot blasting, efficiently and uniformly cleans, strengthens, and prepares metal surfaces in a single pass.

This machine excels in removing rust, scale, old paint, and contaminants from plates, structural steel, castings, and forgings. Beyond cleaning, it simultaneously improves the metal's mechanical properties by inducing compressive stresses, which significantly enhances fatigue life and durability. Engineered for productivity, its continuous operation ensures maximum throughput with minimal manual handling.

It is indispensable across numerous sectors, including metal manufacturing, automotive, wind power, shipbuilding, and structural steel fabrication. Whether preparing I-beams for construction, cleaning train wheels, or descaling metal plates, this machine is a vital investment for achieving superior surface quality, extending product lifespan, and boosting overall manufacturing efficiency.
Upgrade your production line with our reliable passage-type shot blasting solutions today!
